| SIZE | NOS. & DIA OF WIRE/Nom (MAX.) | APPROX DIMENSION OVERALL (MM) | MAX. D.C C.R @ 20° C (COPPER) | MAX. CURRENT CARRING CAPACITY | |
| mm2 | Nos./mm | WIDTH | HEIGHT | 0/1 km | AMPS |
| 3C X 1.5 | 22/0.3 | 13.40 | 6.00 | 12.1 | 19 |
| 3C X 2.5 | 36/0.3 | 14.40 | 6.40 | 7.41 | 24 |
| 3C 4 | 56/0.3 | 17.60 | 7.60 | 4.95 | 35 |
| 3C 6 | 84/0.3 | 19.60 | 8.40 | 3.30 | 42 |
| 3C X 8 | 112/0.3 | 21.90 | 9.30 | 2.48 | 49 |
| 3C X 10 | 140/0.3 | 23.70 | 10.10 | 1.91 | 56 |
| 3C X 12 | 168/0.3 | 26.10 | 10.90 | 1.61 | 65 |
| 3C X 16 | 224/0.3 | 28.00 | 11.80 | 1.21 | 75 |
| 3C X 25 | 354/0.3 | 34.80 | 14.60 | 0.780 | 105 |
| 3C X 35 | 495/0.3 | 38.80 | 16.20 | 0.554 | 130 |
| 3C X 50 | 703/0.3 | 44.80 | 18.60 | 0.386 | 160 |
